Model |
1204 SANDSTOR |
1208 SANDSTOR |
Dimension A
(Bin Sidewall) |
4’-0” |
8’-0” |
Dimension B
(Overall Height) |
20’-7 5/8” |
24’ 7 5/8” |
Dimension C
(Skid Length) |
9’-6 9/16” |
9’-4 7/8” |
Dimension D
(Skid Width) |
6’-5 3/4” |
6’-4 5/8” |
Dimension E
(Circumference) |
11′-6 7/16″ |
11′-4 7/16″ |
Weight |
5,113 lbs. |
6,004 lbs. |
Volume |
800 ft3 |
1,250 ft3 |
- Ladder Cage Package (optional)
- Ladder Lockout (optional)
- Roof Handrail (optional)
- Skid Base (optional)
Meridian Manufacturing warrants all new, unaltered tube conveyors intended for standard or on-farm usage against defects in material or workmanship for a period of one year from the date of purchase. For equipment used in commercial applications, Meridian Manufacturing provides a warranty against defects and workmanship for a period of 90 days.
For components not manufactured by Meridian Manufacturing, such as tires, engines, batteries, etc., please refer to the respective manufacturer for the applicable warranty information. Additional details can be obtained by contacting your authorized Meridian dealer or consulting your owner’s manual.
